AFR-180gsm | 93% M-Aramid, 5% P-Aramid, 2% Antistatic | Twill 2/1 FR

  • Material: • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic
  • Fabric Width(cm): • 151cm(±1cm)/60"
  • Fabric Weight(gsm): • 180GSM
  • Package: • By rolls ,standard export packing, or as customer request
    By rolls 75-100m, standard export packing, inside with plastic bag.
    20"container 40000~45000m
    40"container 55000-60000m

We're here to help:  Easy ways to get the answers you need.

Share With:
  • Technical Data
  • Accreditations & Features
  • Related Products
  • Inquiry

Description of AFR-180gsm - 93% Meta Aramid, 5% Para Aramid, 2% Antistatic FR Fabric


AFR-180 is an inherent protective fabric made of 93% Meta-Aramid, 5% Para-Aramid, 2% Antistatic, with a weight of 180 gsm. It comes in twill 2/1 weave. AFR-180gsm is an innovative inherent flame resistant fabric, owns excellent property of FR, Anti-static, arc proof, wear and tear resistance property. This fabric is best used for FR bibs and FR overalls for workers in the oil and gas, chemical and power industries, flight suits, uniform for petroleum drilling, gas, fire fighting industries etc.

AFR-180 fabric provides protection against Fire, open Flame and Electric Arc. Inherent thermal protection cannot be washed out. The fabric is very durable and super-resistant to abrasion.


AFR-180gsm are light weight and good breathability, which gives extra comfort to the wearer. Due to integrated carbon antistatic yarn, AFR-180gsm prevents building up electrostatic discharge (ESD) and eliminates the possibility of explosion in oil, gas and other industries.



COLOR FASTNESS
Color Change (Washing 60°C) 4-5 ISO 105 C06
Color Staining (Washing 60°C)  4-5 ISO 105 C06
Rubbing Fastness Dry 4-5 ISO 105 X12:1995
Rubbing Fastness Wet 4-5 ISO 105 X12:1995
Light Fastness 4-5 ISO 105 B02







PHYSICAL PROPERTIES
Tensile Strength (N) warp/weft 870/820N ISO 13934-1
Tear Strength (N) warp/weft 36/37N ISO 13937-2
Dimensional Stability to Washing (Max) warp/weft +/-3% ISO 5077
Abrasion resistance           -             ISO12947-2:1999
Pilling Resistance           -             ISO 12945-2:2001

Care Instructions
KEEP IN COOL DRY PLACE, WITH NO DIRECT SUNLIGHT

Accreditations of AFR-180gsm
ISO 11612 (A1, A2, B1, C1, E3, F1) – Protective fabric for industrial workers

EN 1149-5 (1149-3 METHOD 2) – Protective fabric with Antistatic properties, ESD protection

Key Features:
1.Lightweight with protection against flame spread
2.Flame protection is built into the fibers and will never wash out.
3.comfort, softness & breathable
4.Good colour fastness

More Specification we also could made:

  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 260 gsm plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 254 gsm plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 255 gsm plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 254 gsm plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 254 gsm 2/2 twill
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 260 gsm ripstop (square weave)
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 260gsm  3/1 twill
