• Flame Retardant Fabric
  • Flame Retardant Fabric

Inherent FR Fabric NOMEX III 180gsm | 93% Meta Aramid, 5% Para Aramid, 2% Antistatic | Plain 2/1 FR

  • Material: • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic
  • Fabric Width(cm): • 151cm(±1cm)/60"
  • Fabric Weight(gsm): • 180GSM
  • Washing: • 60°C
  • Package: • By rolls ,standard export packing, or as customer request
    By rolls 75-100m, standard export packing, inside with plastic bag.
    20"container 40000~45000m
    40"container 55000-60000m
  • Standard: • ASTM F1959-06 Class 3
    Protection Against Electric Arc
    NFPA2112 HRC 2
    Protection Against Flash Fire
    EN ISO 11611: 2007 A1+A2
    Clothing for Welding and Allied Processes
    EN 1SO 11612:2008 A/B1/C1/E1
    Protection Against Heat and Flame

We're here to help:  Easy ways to get the answers you need.

Share With:
  • Technical Data
  • Service
  • More Products
  • Inquiry

                                                                              INHERENT FR-FABRICS FOR ARMY, RACING AND INDUSTRY

Tianyu Textile have innovated the inherent flame retardant fabrics made of blended aramid fibers in composition of 93% Meta-Aramid, 5% Para-Aramid, 2% Antistatic. Aramid fibers have Inherent thermal, flame and electric arc protection and cannot be washed away.

Garments are made up with aramid fabrics are not flammable. When exposed to flame, the aramid fiber swells and becomes thicker, forming a protective barrier between the heat source and the skin. This protective barrier stays supple until it cools down, giving the wearer vital extra seconds of protection to escape. Tianyu aramid fabrics are very durable, have high tensile resistance and light weight.

1. FR-inherent and Lightweight - Tianyu aramid fabrics are made of synthetic fibers which have inherently flame retardant characteristic. Reputable composition of meta and para-aramid with antistatic provides excellent protection from heat and flame.

2. Internationally Certified - Tianyu aramid fabrics have been certified to main European and American standards. We have done this extensive testing for each of our fr-fabrics in first class world laboratories such as BTTG (UK), Kinectrics (Canada), Vartest (USA), AITEX (Spain), UL (USA). All the Certificates are available on our website.

3. Proven Protection - IS0 11612 / ISO 11611, EN 61482-1-2, ISO 1149-3 - these are the standards, to which we have successfully tested Tianyu aramid fabrics. FR-properties are embedded in the very fibers and can not be ever washed away. FR-inherent properties can not be compromised by even some improper washing method, what gives you extra confidence about your fr-garments.

4. Longer Life of FR-garment and better Colourfastness - using protective garments made with Tianyu aramid fabrics you have a super protection for reasonable price. Due to use of solution dyed (dope dyed) yarn our fabrics keep the original colors during years even after multiple industrial washings.

The garment made by Aramid fabric can be used in various industries, such as  gas station uniform,  firefighter uniform, flight suits for Air-force pilots, combat jackets and pants for Army, Navy and Police uniform, especially for special forces like SWAT, Navy Seals and other elite squats. Tianyu aramid fabrics are also can be used to make coveralls in Auto or Moto-sport or as bibs, overalls, shirts, pants and jackets in Electric companies.



Color fastness
Against light 3-4 ISO 105 B02
Rubbing dry 4 ISO 105 X12
Rubbing wet 4-5 ISO 105 X12
Against perspiration acid / basic 4-5 ISO 105 E04
Washing 60°C 4-5 ISO 105 C06
Washing 60°C staining 4 ISO 105 C06
Dry cleaning 4-5 ISO 105 D01
Abrasion resistance



EN530: class 3-4
Fire retardant performance After Washing 50 Times
After flaming(s) ≤2 0
Afterglow(s) ≤2 0
Damage Length (mm) ≤150 75
Tensile strength ISO 13934-1: warp/weft 730/600N
Tear strength ISO 13937-2: warp/weft 48/39N
Dimensional change ISO 5077: warp/weft +/-1%
Care Instructions
KEEP IN COOL DRY PLACE, WITH NO DIRECT SUNLIGHT

Fire retardant performance After Washing 50 Times

1. The Formaldehyde Content of our Flame Retardant Fabric is less than 300.OG 4.0-7.5

2. Finished by Special Technique with Enviromental Dye and No Carcinogen Aromatic Substance

3. Flame Retardant and Thermal Performance

4. More than 10 years of Experience of US and Europe Markets.

5. Standards: GB8965-2009, En 11612, NFPA2112 etc.
We Guarantee
For New Customer
________________________________________
1.Your kind enquiry will be replied in 2 hours and 24 hours if time difference

2.Price will be offered in 2 hours ,24 hours if time difference.

3.Free sample can be sent for evaluation if in need.

4.Sample making can be made according to your requirements before placing order.

For Old Customer
_______________________________________
1.Shipping samples will be sent for check before shipment.

2.Test report will be sent for evaluation before shipment.

3.Any big quality problem caused by us, money will be return or to do again until meet your requirments.

4.Updating the new products and hot selling products in relative market.

5.Updateing the production schedule regularly.
More Specification we also could made:

  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 260 gsm (Nomex IIIA) plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 254 gsm (Nomex IIIA) plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 255 gsm (Nomex IIIA) plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 254 gsm (Nomex IIIA) plain
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 254 gsm (Nomex IIIA) 2% modacrylic) twill
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 260 gsm (Nomex IIIA) square weave
  • 93% Meta Aramid, 5% Para Aramid, 2% Antistatic, 260gsm (Nomex IIIA) 3/1 twill

* These are regular specifications above, MOQ are 3000 meters for solid dyed fabrics and 5000 meters for pattern printed fabrics.
* Not regular specifications could be customized from 150gsm to 400gsm.


     * These are regular specifications above, MOQ are 3000 meters for solid dyed fabrics.
        we also provide small batch production, please contact us for more information.
     * Not regular specifications could be customized from 150gsm to 400gsm, please contact us for more information。
